VARIADOR DE CA POWERFLEX 755TS
Iniciar sesión para ver precio
VARIADOR DE CA POWERFLEX 755TS
Iniciar sesión para ver precio
VARIADOR DE CA POWERFLEX 755TS XT
Variador de CA PowerFlex 755TS, con doble Embedded EtherNet/IP, protección contra gases corrosivos (XT), entrada de CA con precarga, incluye terminales de CC, IP20/IP00, NEMA/UL tipo abierto, 480 VCA, 3 PH, 22 A, 15 HP ND, 10 HP HD, puente CM instalado, transistor DB, en blanco (sin HIM), Frame 2
Referencia Interna :
20GE1ND022JA0NNNNNUnidad :
Unidades
100% original
Se aceptan devoluciones*
Envio gratis*
| Protección contra la corrosión | XT |
| Corriente / Potencia nominal | 22 A, 15 HP ND, 10 HP HD |
| Frenado dinámico | Transistor DB |
| Tipo de carcasa | Tipo abierto, Frame 2–7 |
| Configuración de filtrado y CM Cap | Puente CM instalado |
| Tamaño de estructura | Frame 2 |
| HIM | En blanco (sin HIM) |
| Tipo de entrada | Entrada de CA con precarga |
| Familia de productos | PowerFlex TS |
| Tipo | 755 AC Drive |
| Clase de tensión | 480 V CA, trifásico |
| Cumplimiento ambiental | Ver detalles | Enviar consulta |
| Información SVHC | Ver guía |
| Availability of firmware updates | 3 Years following release See details |
| Availability of software updates | 3 Years following release See details |
| Ingress protection rating | IP00 |
| Off mode power consumption | 20 W |
| Apparent output power (kVA) | 17.5 kVA |
| Energy efficiency | IE2 |
| Power loss at 0;25 operating condition | 2.3% |
| Power loss at 0;50 operating condition | 2.6% |
| Power loss at 0;100 operating condition | 3.4% |
| Power loss at 50;25 operating condition | 2.5% |
| Power loss at 50;50 operating condition | 2.9% |
| Power loss at 50;100 operating condition | 3.8% |
| Power loss at 90;50 operating condition | 4.4% |
| Power loss at 90;100 operating condition | 4.7% |
| Rated output current (A) | 22 A |
| Rated power output range (kW) | 7.5–11.2 kW |
| Rated supply frequency(s) (Hz) | 60 Hz |
| Rated supply voltage (V) | 480 VAC, 3-phase |
| Standby losses | 0,11% |
| Power consumption | 16442 W |
| Cradle-to-Grave (A1–C4) | 2.09E+01 mol H+ eq |
| Cradle-to-Gate (A1-A3) | 1.85E+00 mol H+ eq |
| Raw Materials (A1) | 1.65E+00 mol H+ eq |
| Supplier Transport (A2) | 1.73E-01 mol H+ eq |
| Manufacturing (A3) | 2.66E-02 mol H+ eq |
| Distribution (A4) | 1.90E-01 mol H+ eq |
| Maintenance (B2) | 1.14E+00 mol H+ eq |
| Use Energy (B6) | 1.78E+01 mol H+ eq |
| End of Life Transport (C2) | 5.57E-04 mol H+ eq |
| Disposal (C4) | 1.43E-03 mol H+ eq |
| Product Carbon Footprint (PCF) | 4.18E+03 kg CO₂ eq |
| System Boundary | Cradle-to-Gate (A1-A3), Cradle-to-Grave (A1–C4) |
| LCA Method | ISO 14040/44 compliant |
| Impact Assessment Method | EF 3.0 (Environmental Footprint) ESPR aligned |
| Database Used | Ecoinvent 3.10 |
| Software Used | SimaPro 9.5 |
| Cut-off Criteria | 1% mass/energy/environmental relevance |
| Allocation Method | Mass-based allocation |
| Year of Facility Data | 2024 |
| Use Phase Grid | EU Average Grid Mix |
| Maximum operating temperature (°C) | 50 °C |
| Unique product identifier | 20GE1ND022JA0NNNNN |
| Unique operator identifier | RA-OP-4000 |
| Importer information | Rockwell Automation N.V Pegasus ParkDe Kleetlaan 12A1831 DiegemBelgium |
| Recyclability Score | 39.299999999999997% |
| Content of recycled product material | 3.1% |
| Repairability score | 92.9 % - A |
| Repair information | See details |
| Repair documentation | Request now |
| Spare part availability | Yes |
| Repair Services | See details |
| 750-tg102_-en-p | 750-TG102 |
| 750-tg104_-en-p | 750-TG104 |
